CAUTION: The following post (or a page linked to) includes or discusses loading data not covered by currently published sources of tested data for this cartridge (QuickLOAD or Gordon's Reloading Tool data is not professionally tested). USE AT YOUR OWN RISK. Neither the writer, The Firing Line, nor the staff of TFL assumes any liability for any damage or injury resulting from the use of this information.
I had lots of fun working up loads for this obscure gun over the summer. Just in case someone is interested - here they are. Warning: These loads were worked up using commercial cases which have a higher capacity than cut down .308 Winchester and NATO Military brass. Start low and work up (like I did!)
Bullet: Sierra 180 gr. JHC
Powder: Winchester 296 29.1 grs.
Primer: Winchester Large Pistol
Case: Starline
OAL: 1.608
Average Velocity: 1700 fps
ES: 24
SD: 9
Bullet: Sierra 180 gr. JHC
Powder: Winchester 296 30.1 grs.
Primer: Winchester Large Pistol
Case: Starline
OAL: 1.610
Average Velocity: 1766 fps
ES: 27
SD: 9
Bullet: Hornady 200 gr. XTP-HP
Powder: Winchester 296 26.0 grs.
Primer: CCI-350
Case: Starline
OAL: 1.600
Average Velocity: 1723 fps
ES: 40
SD: 16
Comment: More velocity with lesser charge when using Magnum Primer.
Bullet: Hornady 200 gr. XTP-HP
Powder: Winchester 296 27.0 grs.
Primer: Winchester Large Pistol
Case: Starline
OAL: 1.598
Average Velocity: 1659 fps
ES: 29
SD: 11
Bullet: Hornady 240 gr. XTP-HP
Powder: Winchester 296 23.5 grs.
Primer: Winchester Large Pistol
Case: Starline
OAL: 1.596
Average velocity: 1506 fps
ES: 29
SD: 10
Bullet: SBR 44 AMP 240 Grain Hornady XTP (Factory)
Case: Starline
OAL: 1.600 – 1.605
Average Velocity: 1503 fps
ES: 24
SD: 8
I had lots of fun working up loads for this obscure gun over the summer. Just in case someone is interested - here they are. Warning: These loads were worked up using commercial cases which have a higher capacity than cut down .308 Winchester and NATO Military brass. Start low and work up (like I did!)
Bullet: Sierra 180 gr. JHC
Powder: Winchester 296 29.1 grs.
Primer: Winchester Large Pistol
Case: Starline
OAL: 1.608
Average Velocity: 1700 fps
ES: 24
SD: 9
Bullet: Sierra 180 gr. JHC
Powder: Winchester 296 30.1 grs.
Primer: Winchester Large Pistol
Case: Starline
OAL: 1.610
Average Velocity: 1766 fps
ES: 27
SD: 9
Bullet: Hornady 200 gr. XTP-HP
Powder: Winchester 296 26.0 grs.
Primer: CCI-350
Case: Starline
OAL: 1.600
Average Velocity: 1723 fps
ES: 40
SD: 16
Comment: More velocity with lesser charge when using Magnum Primer.
Bullet: Hornady 200 gr. XTP-HP
Powder: Winchester 296 27.0 grs.
Primer: Winchester Large Pistol
Case: Starline
OAL: 1.598
Average Velocity: 1659 fps
ES: 29
SD: 11
Bullet: Hornady 240 gr. XTP-HP
Powder: Winchester 296 23.5 grs.
Primer: Winchester Large Pistol
Case: Starline
OAL: 1.596
Average velocity: 1506 fps
ES: 29
SD: 10
Bullet: SBR 44 AMP 240 Grain Hornady XTP (Factory)
Case: Starline
OAL: 1.600 – 1.605
Average Velocity: 1503 fps
ES: 24
SD: 8
